AM41, Split Flow Hydraulic Manifold, 1 inlet, 4 outlet ports
Item ID: AM41
$1,541.02
Free Shipping
Product Description
AM-Series hydraulic manifolds can be used to split the flow from a single inlet port to 2 or 4 outlet ports. The integral needle valve handles on each port are used to switch the flow on or off.
All ports connections are 3/8"-18 NPTF and both models have a maximum operating pressure of up to 10,000 psi (700 bar).
AM21 has 2 outletsAM41 has 4 outlets
Product Specifications
Maximum Operating Pressure (bar)700
Maximum Operating Pressure (psi)10000
Product TypeSplit Flow Manifold
About this Product
AM-Series hydraulic manifolds can be used to split the flow from a single inlet port to 2 or 4 outlet ports. The integral needle valve handles on each port are used to switch the flow on or off.
All ports connections are 3/8"-18 NPTF and both models have a maximum operating pressure of up to 10,000 psi (700 bar).
AM21 has 2 outletsAM41 has 4 outlets
Features
- Functions as split-flow valve to control single-acting cylinders simultaneously
- Handle used to open and close each port
- Easy to connect
- Mounting holes on all models
- All ports 3/8"-18 NPTF.
- Maximum pressure up to 10,000 psi (700 bar)
