SC1, 2164 lbs Force, Swing Clamp, 1.49 in Stroke
Item ID: SC1
$1,182.64
Free Shipping
Product Specifications
Product TypeSwing Clamp
Dimension G1 (in).125 - 27
Dimension D2 (mm)48
Available - Backorder
About this Product
Features
- Changeable swing function: clamp arm movement can be adjusted to left or right swing, or straight pull function
- 88-92° clamp arm swing arc
- Easy installation: built-in mountings and brackets
- Compact design for use in limited space applications
- Easy and precise locating of arm for clamp positioning
- Single or double-acting cylinders to suit variety of hydraulic requirements
Units:
Clamping Force (lbs)2164
Stroke (inch)1.49
Stroke Clamping (in)0.5
Cylinder Effective Area Pull (in2)0.98
Cylinder Effective Area Push (in2)1.767
Oil Capacity Pull (in3)1.47
Oil Capacity Push (in3)2.65
Weight (lbs)6
80%
Think Safety
Manufacturer's rating of load and stroke are maximum safe limits. Good practice encourages using only 80% of these ratings!
Units:
Dimension A8.88"
Dimension B7.37"
Dimension C5.87"
Dimension D1.875 - 16 un"
Dimension F1"
Dimension G.250 - 18"
Dimension H3.31"
